AD-Series High Precision Planetary Gearboxes
AD-Series High Precision Planetary Gearboxes
The Apex AD series High Torque, Low backlash COMPACT Helical, One Piece Plantary Cage Design Provides the Stiffest and Most Accurate Rotating Flange Design on the Market Today. Superior Accuracy of less than 1 arc-min and as SHORT as 70mm (Flange to Flange), The Apex AD fits into the smallest spaces.
Enquire Now
- Output torque
T2N : 14 Nm - 2000 Nm
- Ratios
1-stage : 4 / 5 / 7 / 10
2-stage : 20/25/35/40/50/70/100/16/21/31/61/91
- Low backlash
1-stage : ≤1 arcmin / ≤3 arcmin / ≤5 arcmin
2-stage : ≤3 arcmin / ≤5 arcmin / ≤7 arcmin
- high efficiency
1-stage : ≧ 97%
2-stage : ≧ 94%
- Easy mount
- Low Noise
- Compact structure
