AB-Series High Precision Planetary Gearboxes
AB-Series High Precision Planetary Gearboxes
Powerful, precise, robust, quiet and fast, suitable for all servo applications.The Apex AB series is the Next generation in planetary technology. Highest Precision, Highest Torque and Quiet Operation are provided by 100% optimized Helical Gearing. Straddle Mounted High Precision Bearings Allow for High Radial and Axial Loads. Dimensions
Enquire Now
Overview
- Output torque T2N : 14 Nm - 2000 Nm
- Ratios
- 1-stage : 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10
- 2-stage : 15 / 20 / 25 / 30 / 35 / 40 / 45 / 50 / 60 / 70 / 80 / 90 / 100
- Low backlash
- 1-stage : ≤1 arcmin / ≤3 arcmin / ≤5 arcmin
- 2-stage : ≤3 arcmin / ≤5 arcmin / ≤7 arcmin
- High efficiency
- 1-stage : ≥97%
- 2-stage : ≥94%
- Easy mount
- Low Noise
- Compact structure
- All sizes available
- AB042 / AB060 / AB060A / AB090 / AB090A / AB115 / AB142 / AB180 / AB220
